USED SMG 10 – 40 Bed Type Bar Threading Machine (3/8 – 1-1.2′′)
$17,500.00 Excl. GST
$19,250.00 Incl. GST
Used SMG 10 – 40 Bed Type Bar Threading Machine is ideal for rapid external bolt and bar threading. The rotating head allows for the bar to be clamped securely on the saddle, increasing rigidity for excellent efficiency and faster threading times.
USED SMG 10 – 40 Bed Type Bar Threading Machine (3/8 – 1-1.2′′)
USED SMG 10 – 40 Bed Type Bar Threading Machine (3/8 – 1-1.2′′)
Description
Used SMG 10 – 40 Bed Type Bar Threading Machine is ideal for rapid external bolt and bar threading. The rotating head allows for the bar to be clamped securely on the saddle, increasing rigidity for excellent efficiency and faster threading times.
The Used SMG 10 – 40 Bed Type Bar Threading Machine has only cut approximately 1,000 bars. The original grease is still on the threading machine, indicating it has been hardly used. Also the machine is brand new since the time of purchase
A wide range of Tangential Die Chasers are available for:
BSW, UNF, METRIC, UNC, ACME Bolt and bar threading.
Key Features:
- Robust headstock fitted with case hardened gears and oversized spindle bearings.
- Hard chrome plated pillar type slideways
- Hardened heat-treated vice jaws
- High-Speed Steel Tangential Die Chasers
- Recirculating lubrication system
- 2 Speed spindle
Specifications
| MODEL | SMG 10/40 (3/8″ to 1.1/2″) BED TYPE |
| Saddle Movement | 330mm (13″) |
| Spindle Speed Range | 75 -140rpm |
| Number of Spindle Speed | 2 |
| Threading Capacity | 10 – 40mm (3/8″ to 1.1/2″) |
| Production per Hour | 60-80 |
| Drive Motor | 2.2kw / 3 H.P. |
| Lead Screw | Optional |
| Weight Approx. | 550 kg |
SMG 10 – 40 Bed Type Bar Threading Machine
How to Use SMG 10-40 Bar Threading Machine
Frequently Asked Questions
Should I purchase industrial machinery from a tool shop or reseller, or from an industrial machinery specialist?
Tool shops and general resellers may offer a wide product range, but often lack the specialised knowledge to properly assess applications or provide ongoing technical support. An industrial machinery specialist ensures the right machine is selected and fully supported long after purchase. In most cases, buying directly from the importer or specialist also results in a lower purchase cost, as additional reseller margins are not added.
What after-sales support and warranty do you provide?
Industry leading after-sales support, Australia-wide.
Backed by over 30 years of industry experience, more than two decades in business, and a long history of satisfied customers Australia-wide, Capital Machinery Sales provides after-sales support you can count on, long after your machine is delivered, backed by our dedicated support team.
- Application support: Whether your requirements are straightforward or highly specific, we work with you to ensure your machine is set up and performing for your exact application, and we are here to help as your needs evolve.
- Pre-dispatch testing: Every machine is fully checked and commissioned before it leaves us. It's a step that saves our customers countless issues down the track and sets your machine up for maximum uptime.
- Warranty: We don't just pass on the manufacturer's warranty. We offer our own comprehensive warranty that goes further, giving you greater coverage and peace of mind, with extended warranty options also available.
- Spare parts: Downtime costs you money, so minimising it is our priority. We keep a wide range of parts and consumables in stock, and if we don't have it on the shelf, we will track it down and get it to you as fast as possible.
- Remote support: Fast help via phone, email, or live video, with no site visit needed in most cases. We pride ourselves on some of the fastest response times in the industry, because we know that when you need help, you need it now.
- On-site service: Our engineers travel Australia-wide, with trusted contractors covering remote areas.
- In-house repairs: Send your machine back to us for expert servicing and overhaul.
How quickly will I receive my machine?
Often, we can ship the same day if required, depending on stock availability, the time your order is placed and the available shipping options.
Specification
Additional information
| Weight | 550 kg |
|---|---|
| Dimensions | 180 × 115 × 150 cm |
