PortaForce PF500PTP-A Pneumatic Torque Pump – 1.3kW / 1.74HP – 0.03-0.28 CFM / 0.8-8
PortaForce PF500PTP-A Pneumatic Torque Pump – 1.3kW / 1.74HP – 0.03-0.28 CFM / 0.8-8 LPM is designed to deliver reliable power for torque wrenches applications. Using compressed air as its source, it’s ideal for demanding environments like coal mines and other industrial sites where safety, durability, and long-term performance are essential.
PortaForce PF500PTP-A Pneumatic Torque Pump - 1.3kW / 1.74HP - 0.03-0.28 CFM / 0.8-8
PortaForce PF500PTP-A Pneumatic Torque Pump - 1.3kW / 1.74HP - 0.03-0.28 CFM / 0.8-8
Description
PortaForce PF500PTP-A Pneumatic Torque Pump – 1.3kW / 1.74HP – 0.03-0.28 CFM / 0.8-8 LPM is designed to deliver reliable power for torque wrenches applications. Using compressed air as its source, it’s ideal for demanding environments like coal mines and other industrial sites where safety, durability, and long-term performance are essential.
Features:
- Uses compressed air for safe, heat-free, and long-lasting operation.
- Anti-explosion design ensures safety in hazardous work areas.
- High-performance pneumatic reversing valve for stable and reliable output.
- Durable, lightweight aluminium alloy pump body for easy handling.
- Can operate 2 or 4 wrenches at the same time.
- Adjustable working pressure up to 70MPa with 4–8 bar air supply.
- Customizable pump configurations available on request.
- Easy pressure release with a push-button function.
- Protective steel frame for pump safety and convenient transport.
- Solid, reliable aluminium explosion-proof handle.
PortaForce PF500PTP-A Pneumatic Torque Pump & Bolt Tensioner Pump Diagram
| Model | PF500PTP-A |
| Pressure (bar) | 4-8 |
| Rated Power (kw) | 1.3 |
| Air Consumption (M3/H) | 134 |
| Pressure (High) | 70 Mpa |
| Pressure (Medium) | 32 MPa |
| Pressure (Low) | 6 MPa |
| Flow (High) |
0.8 LPM / 0.02 CFM
|
| Flow (Medium) |
1.6 LPM / 0.06 CFM
|
| Flow (Low) |
8 LPM / 0.28 CFM
|
| Oil Tank Capacity | 8 litres |
| Dimension |
42.8 cm × 28.1 cm × 44.8 cm
|
| Weight | 21 kg |
