Description

2021FrameMac Instruction Manual

The Used FrameMac F1-C89 Light Gauge Steel Press Machine (2021) is designed for use in modern steel framing systems, supporting the manufacturing of components used in residential, commercial, and modular building construction. Suitable for workshops involved in steel frame construction, the machine enables efficient processing of steel elements used in prefabricated building structures.

The hydraulic system uses a constant-pressure design that helps maintain stable operating pressure and stiffness while reducing energy loss and excess heat generation within the system. This configuration improves operational reliability and helps extend the service life of hydraulic components during continuous production cycles.

Integrated safety features such as a pressure relief valve and pressure monitoring sensor help protect the machine from excessive pressure conditions while allowing operators to gauge system performance in real time.

For workshops producing components through cold roll forming machines, custom roll forming processes, or integrated steel framing machines, the FrameMac F1-C89 press machine supports consistent processing of structural steel sections used in lightweight framing structures, including those utilizing light gauge steel.

The machine layout and control interface help reduce physical strain during repetitive operations. The design supports smoother handling and reduced operator fatigue during extended production runs, helping maintain safer working conditions in fabrication environments.

Overall, the machine offers a practical solution for manufacturers seeking dependable construction machinery for light gauge steel framing production.

Key Features and Benefits

High-Efficiency Hydraulic System – Maintains stable pressure to ensure consistent punching and forming performance during steel framing production.
Optimised Production Speed – Operating speed of up to 15 m/min supports efficient manufacturing of light gauge steel components.
Robust Construction Machinery Design – Built to support industrial environments with the strength needed for light gauge steel framing solutions and prefabricated building production.
Large Hydraulic Oil Capacity – 120L tank supports stable pressure control and long operational cycles.
Precision Press Functionality – Designed to assist in processing light gauge steel sections used in steel frame construction systems.
User-Controlled Speed Regulation – Hydraulic speed control allows adjustment of the cylinder working speed for improved processing control.
Integrated Safety Pressure Control – Relief valve system helps gauge and prevent over-pressure conditions to protect equipment and operators.

Specifications

Model	Used 2021 FrameMac F1-C89
Motor Power	2.2 kW
Bore	450 – 530 mm
Maximum Volume	1200 mm
Speed	15 m/min
Hydraulic Tank Capacity	120 L
Dimension	1900 × 900 × 1200 mm
Weight	5000 kg

Shipping & Installation

Machine Dimensions: 1900 × 900 × 1200 mm using light gauge steel for construction
Approximate Machine Weight: Up to 5000 kg
Dependable transport and packaging arrangements handled by the seller.
Suitable for workshop installation with appropriate power supply, especially when using light gauge steel construction materials
Requires 380V 50Hz three-phase power supply for operation.
Professional installation and commissioning recommended for optimal performance

Cold-formed Light Gauge Steel – Australian Steel Institute

For ongoing support, the FrameMac F1-C89 is backed by comprehensive after-sales service, including access to spare parts and technical assistance throughout the warranty period. Users benefit from responsive customer support for troubleshooting, maintenance guidance, and supply of consumables, ensuring minimal downtime and sustained productivity. This commitment to service makes the FrameMac F1-C89 a practical choice for businesses seeking reliability and long-term value in light gauge steel framing operations, steel frame construction, cold-formed steel manufacturing, prefabricated building systems, and modular construction projects. The machine’s compatibility with modern steel framing techniques and its robust design further support efficient production of steel studs, tracks, and other structural components used in light gauge steel applications.

Frequently Asked Questions

Should I purchase industrial machinery from a tool shop or reseller, or from an industrial machinery specialist?

Tool shops and general resellers may offer a wide product range, but often lack the specialised knowledge to properly assess applications or provide ongoing technical support. An industrial machinery specialist ensures the right machine is selected and fully supported long after purchase. In most cases, buying directly from the importer or specialist also results in a lower purchase cost, as additional reseller margins are not added.

What after-sales support and warranty do you provide?

Industry leading after-sales support, Australia-wide. Backed by over 30 years of industry experience, more than two decades in business, and a long history of satisfied customers Australia-wide, Capital Machinery Sales provides after-sales support you can count on, long after your machine is delivered, backed by our dedicated support team.

Application support: Whether your requirements are straightforward or highly specific, we work with you to ensure your machine is set up and performing for your exact application, and we are here to help as your needs evolve.
Pre-dispatch testing: Every machine is fully checked and commissioned before it leaves us. It's a step that saves our customers countless issues down the track and sets your machine up for maximum uptime.
Warranty: We don't just pass on the manufacturer's warranty. We offer our own comprehensive warranty that goes further, giving you greater coverage and peace of mind, with extended warranty options also available.
Spare parts: Downtime costs you money, so minimising it is our priority. We keep a wide range of parts and consumables in stock, and if we don't have it on the shelf, we will track it down and get it to you as fast as possible.
Remote support: Fast help via phone, email, or live video, with no site visit needed in most cases. We pride ourselves on some of the fastest response times in the industry, because we know that when you need help, you need it now.
On-site service: Our engineers travel Australia-wide, with trusted contractors covering remote areas.
In-house repairs: Send your machine back to us for expert servicing and overhaul.

We’re in this together. Our shared goal is to keep your business running, and we are committed to delivering the best after‑sales service in the industry to make that happen. That’s why so many of our customers have been with us for years, and why they continue to return. Need service, application advice, or want to discuss a support plan? Contact our team and we will take care of it.

How quickly will I receive my machine?

Often, we can ship the same day if required, depending on stock availability, the time your order is placed and the available shipping options.

Specification

Additional information

Weight	900 kg
Dimensions	190 × 90 × 120 cm
Motor Power	2.2 kW
Machine Weight	5000kg
