WiseLasers EVO-3000W Handheld Fiber Laser Welder/Welding Machine

Was $ 25,816 Excl. GST $ 28,398 Incl. GST Now Only $22,718.08 Excl. GST $24,989.89 Incl. GST

In stock

One Only Sydney Expo Special

The WiseLasers EVO3000W Handheld Fiber Laser Welder/Welding Machine that comes with a variety of impressive features and advantages. It offers a welding speed that is up to 4 times faster than TIG, making operations more efficient and time-saving.

Request Quote / Check stock / Questions
Click Here
Please note: This is the fastest way to receive an answer.
Stock levels cannot be checked over the phone.
Product ID: WISELASERS-EVO3000W Categories: , Tags: , , Brand:
Was $ 25,816 Excl. GST $ 28,398 Incl. GST Now Only $22,718.08 Excl. GST $24,989.89 Incl. GST

Description

The WiseLasers EVO-3000W Handheld Fiber Laser Welder/Welding Machine comes with a variety of impressive features and benefits.

Offering a welding speed that is up to 4 times faster than conventional TIG, greatly improving efficiency and labour costs. Moreover, the laser welding process using the world-renowned Raycus laser source produces high-quality results when welding many different metals, no matter how thick, thin or reflective the material may be.

The precision laser source reduces the chance of distortion, deformation, undercut, or burn-through. This guarantees consistent weld results and reduces the need for extensive setup and rework. The handheld design of the machine offers excellent flexibility and convenience, making it suitable for welding in various environments.

The EVO-3000W is designed to be ergonomic and user-friendly, allowing both beginners and experienced welders to utilise full functionality effectively offering exceptional performance and ease of use, making it a valuable tool for professionals in the welding industry.

The Process

Laser welding utilizes the directivity and high power density of the laser beam. The laser is generated and transmitted through a flexible optical fibre. It is then focused by a lens in the welding head and applied to the weld seam between the processed materials. Shielding gas is used to prevent oxidation and liquefy the material, creating a specific molten pool for welding purposes.

Features
  • Full local support, service, consumables and spare parts.
  • Built with industry leading component brands.
    • Raycus Laser Source
    • S&A Water Chiller
    • Meanwell power supply and high quality switch gear
  • Easy to set up learn and operate.
  • The touchscreen controller has preset welding cycles taking the guesswork out of setup.
  • Welding Speed up to 4x faster than TIG.
  • Produces high quality welding of thick, thin and reflective metals without distortion, deformation, undercut or burn-through.
  • Simpler setup and eliminates the need for rework.
  • Flexible and convenient for welding work.
  • Versatile in welding different metal materials including carbon steel, stainless steel, high-strength steel, aluminium, copper, and alloys.
  • The laser can be set to emit light continuously or in pulses, enabling both heat conduction welding and continuous deep penetration welding.
  • This laser machine can be used for spot welding, butt welding, stitch welding, sealing welding, seam welding, and more.
  • The Raycus fibre laser source offers outstanding beam quality, requires no maintenance, and boasts a photoelectric conversion efficiency of over 25%.
  • The water cooler has a service life exceeding 100,000 hours.
  • The equipment is compact and portable, making it convenient for welding large workpieces over long distances. Additionally, it is suitable for outdoor welding.
  • The welding seam physically looks great and produces minimal deformation, saving the costs of grinding or straightening.
  • Laser welders are very energy efficient consuming much less electricity than traditional welding methods, resulting in lower equipment operating costs.



Raycus Laser Source and S&A Water Chiller
raycus laser source s a water chiller for wiselasers evo1500w handheld fiber laser welder welding machine
Samples



WiseLasers EVO Series Handheld Fiber Laser Welder Welding Machine Video




Specification:
Laser type Continuous fiber laser
Output rating power 3000W
Power regulation range 10% – 100%
Laser central wavelength 1080±3nm
Output mode Continuous/modulation
Maximum modulation frequency 50kHz
Power instability <3%
Optical fiber output interface QBH
Indicating system Red Laser
Optical fiber core 50μm
Optical fiber length 15mm
Welding torch cable length 10m
Type of welding gun Left and right oscillating galvanometer welding head
Collimating focal length 50mm
Focused focal length 150mm/200mm
Wire feeding diameter 0.8, 1.0 ,1.2, 1.6
Welding torch weight 0.8kg
Protective gas mode Coaxial protection
Adjustable width of weld seam 0-6mm
Water flow >25L/min
Product mix Integrated
Product size L*D*H 1250* 510*1170mm
Product weight 320kg
Operating ambient temperature 10°C – 40°C
Working environment humidity <70%
Operating voltage Single phase 220VAC
Whole machine power <17kw
Maximum Welding Thickness:
Metal Material 1500W 2000W 3000W
Stainless Steel 4.5mm 6.5mm 7.5mm
Mild Steel 4.5mm 6.5mm 7.5mm
Aluminium alloy 4mm 5.5mm 6mm
Aluminium  3mm 4.5mm 5mm
Galvanized sheet 3.8mm 5mm 5.5mm
Brass 1.5mm 2.5mm 3.5mm
Red Copper 1.2mm 2mm 3mm



Note: The maximum thickness mentioned above includes the use of filling wire. If the gap or seam is less than 0.3mm, welding can be done without filling wire. The maximum thickness increases by 1mm for each incremental step.
